SPECIFICATIONS
MAX LOAD 200 KGS
NET WEIGHT 700 KGS
MAX PLATFORM HEIGHT 12 MTR
PLATFORM SIZE 1.45MTR (LENGTH) X 0.60 MTR (WIDTH)
BASE SIZE 1660MM X 970MM X 2000MM (CLOSED SIZE)
POWER 1.5 KW
VOLTAGE 220V
PLATFORM STEEL
THICKNESS 4MM
TUBE SIZE 50MM X 30MM X 3 MM (THICKNESS)
SUPPORT ALUMINUM T6005
BASE PART MADE BY SQUARE STEEL PIPE, 100MM X 50MM,
PLATE IS WITH 4MM THICKNESS MADE FROM POLYESTER
| DESCRIPTION | |||||
| User-friendly ground and platform controls offer quick setup and simple operation | |||||
| Rocker base system makes it easy to maneuver around and over obstacles | |||||
| Small outrigger footprint allows for positioning close to walls | |||||
| Ground fault interrupter receptacle on the platform allows for safe use of power tools | |||||
| Auxiliary platform-lowering bypass for descent in the event of a power failure |
